TVLogic F-7HS - MAX BRIGHTNESS; FIRMWARE UPGRADE

38
FHD Hight Bright Field Monitor
07 OTHER FUNCTIONS
[13] MAX BRIGHTNESS
[14] FIRMWARE UPGRADE
• This function sets the brightness of the panel.
• Available values are below :
- INDOOR : 100 nits
- OUTDOOR : 1500 nits
- MAXIMUM : 1800 nits
• The USB(Thumb drive) which contains the F/W le is needed for Firmware Upgrade.
• Select the SW UPGRADE in the SYSTEM menu.
1. Connect the USB to the USB Slot on the bottom of the monitor.
2. Go to [MENU] → [SYSTEM] → [SW UPGRADE], and select what to update among ALL, CPU, FPGA, IMAGE.
3. When the USB connection is completed, the S/W upgrade starts and the progress displays on the
bottom left side of the screen.
4. If the USB doesn’t connect properly or there is no le in the specied location, the error message will
be displayed on the bottom left side of the screen and the upgrade won’t start.
5. In that case, check the USB or the le location and try again.
• After USB connection, turn o and then on the monitor.
