TVLogic LVM-075A User Manual

50 Multi Format LCD Monitor
10. Product Specifications
* The specication above may be changed without notice.
LVM-232W
LCD
Size 23”
Resolution 1920 X 1080 (16:9)
Pixel Pitch 0.265(H) X 0.265(V) mm
Color Depth 16.7M (Dithered 8bit)
Viewing Angle H : 178 degrees / V : 178 degrees
Luminance of white
300 cd/ m
2
(Center)
Contrast Ratio 1000 : 1
Display Area 509.18(H) X 286.42.6(V) mm
Input Connector
1 X DVI-I DVI-IN
1 X BNC
CVBS Input
1 X BNC SDI Channel Input
1 X HDMI HDMI Input
Output
1 X BNC
CVBS Output
1 X BNC SDI Channel (Active Through Out)
Input Signal
Analog Composite
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
DVI VESA/IBM Modes
HDMI 480i / 480p / 720p / 1080i VESA/IBM Modes
Analog Input Spec Composite 1.0Vpp (with Sync)
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
Audio In Embedded Audio / Analog Stereo (Phone Jack)
Audio Out Analog Stereo (Phone Jack), Speaker (Mixed Mono)
Power AC 100~240V (50~60Hz)
Power Consumption (Approx.) 60 Watts(Max. 5A)
Operating Temperature
0℃ to 40℃ (32
℉
to 104
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 552.5 x 354 x 66.1 (21.75 x 13.94 x 2.60)
Main Body Dimensions with stand (mm/inch) 599.7 x 381.8 x 142 (23.61 x 15.03 x 5.59)
Box Dimensions (mm/inch) 675 X 535 X 280 (26.57 X 21.06 X 11.02)
Weight 6.9kg / 15.21lbs
Basic Accessories AC Power Cord / Stand / Manual
Optional Accessories Rack Mountable Kit, Acrylic Filter
