07 BUTTON FUNCTIONS
31
Multi Format LCD Monitor
• LVM-180A monitor supports HDMI/DVI digital
input signal.
1. Press [DIGITAL] in front of the monitor and the
OSD menu appears as the picture below.
Select input you would like to use by the UP/
DOWN knob and press the knob.
2. The information of the current input signal
appears on the bottom of OSD.
3. Press [DIGITAL] again, then the OSD menu
disappears.
#If no image displays after selecting the
desired input mode, check and make sure that
your connection is not lose or disconnected.
Multi Format LCD Monitor
• LVM-180A monitor supports various analog
input signals.
1. Press [ANALOG] in front of the monitor and
the OSD menu appears as the picture below.
Select the input you would like to use by the
UP/DOWN knob and press the knob.
2. The information of the current input signal
appears on the bottom of OSD.
3. Press [ANALOG] again, then OSD menu
disappears.
#If no image displays after selecting the desired
input mode, check and make sure that your
connection is not lose or disconnected.
<Warning!!>
When using ANALOG mode, always check the
input method
and modify the setting as needed for optimized
output results.
[1] ANALOG [2] DIGITAL INPUT
