TVLogic LVM-180A User Manual

05 MENU OPERATIONS
13
Multi Format LCD Monitor
13
• Brightness
- This item controls the degree of brightness
between [-100] and [100].
#Brightness can be adjusted by using a control
knob on the front of the monitor.
• Contrast
- This item controls contrast ratio between
[-100] and [100].
#Contrast ratio can be adjusted by using a
control knob on the front of the monitor.
• Chroma
- This item controls saturation between
[-50] and [50].
#Chroma can be adjusted by using a control
knob on the front of the monitor.
• Phase
- This item controls phase value (Hue) between
[-180] and [180].
#This function activates only with analog video
input signal.
• Aperture
- This item controls the picture sharpness
between [0] and [24].
#Sharpness can be adjusted by using a control
knob on the front of the monitor.
• NTSC Setup
- This item sets NTSC IRE value for [0 IRE]
(Zero setup) or [7.5 IRE].
- It is activated only in COMPOSITE 1/2/3 or
S-VIDEO mode when the NTSC signal is input.
• Key Lock
- This item locks all buttons except for power,
source change and menu button in front of
the monitor.
• Output Mode Select
- Used to select the range of luminance between
[Full] (255) and [Limited] (235).
Multi Format LCD Monitor
LVM-180A
[1] PICTURE
