TVLogic LVM-180A User Manual

09 VIDEO SUPPORT RESOLUTION
40
Multi Format LCD Monitor
[1] SDI MODE
Input Signal
Interface
Signal Format (SD SDI)
SD-SDI
720x487(59.94i)
720x576(50i)
YCbCr 4:2:2 10bit
Input Signal
Interface
Signal Format (SD SDI)
HD-SDI
1920x1080(23.98/24/25/29.97/30p)
(50/59.94/60i) (24/25/29.97/30psf)
1280x720(50/59.94/60P)
YCbCr 4:2:2 10bit
Input Signal
Interface
Signal Format (SD SDI)
3G-SDI (A/B)
1920x1080(60p/59.94p/50p) Y CbCr 4:2:2 10bit
1920x1080(30/29.97/25/24/23.98/
30sF/29.97sF/25sF/24sF/23.98sF)
RGB 4:4:4 10bit / 12bit
YCbCr 4:4:4 10bit / 12bit
[2] DVI-ANALOG MODE
Resolution Frequency
zH57 ,zH06 084 x 046
zH07 004 x 027
zH57 ,zH27 ,zH06 006 x 008
zH57 ,zH07 ,zH06 867 x 4201
zH57 / zH06 867 x 6631
