39
Multi Format LCD Monitor
08 OTHER FUNCTIONS
[9] INTERNAL PATTERN [10] INPO.
• Displays the internally generated test patterns
- The internal test pattern consists of
ColorBar+Pluge and Gray.
The full screen of various gray levels(0~100%)
are also embedded.
• Displays the current status and function setting
of the monitor.
• It displays when you press [INFO.] button in
front of the monitor.
[Format]: Current input signal
[Color Temp]: Current color temperature
[F1][F2][F3][F4][F5]: Current hot-key setting status
[Scan]: Current scan setting status
[Aspect]: Current aspect ratio setting status
[Waveform]
[A.L.M]
[User cong]
[Time code]
[Focus Assist]
[Captions]
[UMD Display]
[Key LED]
[Remote ctrl]
[Fan enable]
<Color Bar + Pluge Pattern>
<Gray Pattern>
