32
Multi Format LCD Monitor
[3] SDI INPUT [4] FUNCTION KEY SET
07 BUTTON FUNCTIONS
• The Function Keys allow the user to activate
the desired functions quickly.
1. Hold [F1] to [F5] key in front of the monitor for
more than 2 seconds and the OSD menu
appears as the picture below.
2. Select input you would like to use by the
UP/DOWN knob.
3. Afterward, [F1] to [F5] keys perform the
designated functions.
Multi Format LCD Monitor
• LVM-180A monitor supports the two HD/SD/
3G-SDI inputs.
1. Press [SDI-A] or [SDI-B] in front of the monitor.
2. The information of the current input signal
appears on the bottom of OSD.
3. Press [SDI-A] or [SDI-B] again, then OSD menu
disappears.
#If no image displays after selecting the desired
input mode, check and make sure that your
connection is not lose or disconnected.
