TVLogic TSM-232W User Manual

TVLogic Security Monitor 29
10. Product Specifications
* The specication above may be changed without notice.
TSM-182W
LCD
Size 18.5”
Resolution 1366 X 768 (16:9)
Pixel Pitch 0.300(H) X 0.300(V) mm
Color Depth 16.7M (Dithered 8bit)
Viewing Angle H : 178 degrees / V : 178 degrees
Luminance of white
300 cd/ m
2
(Center)
Contrast Ratio 1000 : 1
Display Area 409.8(H) X 254.6(V) mm
Input Connector
1 X DVI-I DVI-IN
1 X BNC
CVBS Input
1 X BNC SDI Channel Input
1 X HDMI HDMI Input
Output
1 X BNC
CVBS Output
1 X BNC SDI Channel (Active Through Out)
Input Signal
Analog Composite
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
DVI VESA/IBM Modes
HDMI 480i / 480p / 720p / 1080i VESA/IBM Modes
Analog Input Spec Composite 1.0Vpp (with Sync)
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
Audio In Embedded Audio / Analog Stereo (Phone Jack)
Audio Out Analog Stereo (Phone Jack), Speaker (Mixed Mono)
Power AC 100~240V (50~60Hz)
Power Consumption (Approx.) 60 Watts(Max. 5A)
Operating Temperature
0℃ to 40℃ (32
℉
to 104
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 442.5 x 309.2 x 65.4 (17.42 x 12.17 x 2.57)
Main Body Dimensions with stand (mm/inch) 482.5 x 333.4 x 137.5 (18.99 x 13.13 x 5.41)
Box Dimensions (mm/inch) 550 X 450 X 280 (21.65 X 17.72 X 11.02)
Weight 5.1kg / 11.24lbs
Basic Accessories AC Power Cord / Stand / Manual
Optional Accessories Rack Mountable Kit, Acrylic Filter
