TVLogic Security Monitor 27
9. DVI / HDMI Support Resolution
DVI ANALOG / DIGITAL /HDMI SUPPORT RESOLUTION (TSM-182W)
● DVI-ANALOG mode supports the following modes :
● DVI DIGITAL Graphic mode supports the following modes :
● DVI DIGITAL Video mode supports the following input signals :
● DVI DIGITAL mode is separated into Graphic mode and Video mode.
● In DVI ANALOG/DIGITAL mode, ZERO scan must be selected for normal function.
● If the input image is in non-wide mode, press ASPECT button to change to wide display.
Resolution Frequency
640 X 480 60Hz, 75Hz
720 X 400 70Hz
800 X 600 60Hz, 72Hz, 75Hz
1024 X 768 60Hz, 70Hz, 75Hz
1366 X 768 60Hz / 75Hz
Resolution Frequency
640 X 480 60Hz, 75Hz
800 X 600 60Hz, 72Hz, 75Hz
1024 X 768 60Hz, 70Hz, 75Hz
1366 X 768 60Hz / 75Hz
SMPTE-274M 1080i (60 / 59.94)
SMPTE-296M 720i (60 / 59.94)
SMPTE-125M 480i (59.94), 480p (59.94)
To Next Page
