26 TVLogic Security Monitor
● Displays current status and function
setting of the monitor.
● It displays when you press [Info.] in front
of the monitor.
1. [Format] : Current input signal for main
picture and PIP picture
2. [PIP Mode] : Current status of PIP activating
3. [Color Temp.] : Current color temperature
4. [Scan] : Current scan setting status
5. [Aspect] : Current aspect ratio setting status
6. [User cong.]
7. [Key LED]
[12] INFO.
8. Other Functions
[11] SWAP
● The function exchange main picture and
PIP/PBP picture in PIP/PBP mode.
<SWAP in PIP mode>
<SWAP in PBP mode>
