TVLogic Security Monitor 25
[9] PIP [10] POSITION
● The function activates PIP function and
adjusts PIP picture size.
1. PIP picture sizes are PIP SMALL and PIP
LARGE.
* You cannot use HDMI and DVI-Digital
together in PIP function at the same time.
● The function changes PIP picture position.
1. PIP picture positions are BOTTOM-LEFT,
BOTTOM-RIGHT, TOP-LEFT and TOP-RIGHT.
8. Other Functions
<Bottom-Left> <Bottom-Right>
<Top-Left> <Top-Right>
<PIP picture position>
<PIP MODE>
