MAINTENANCE
MAINTENANCE
PERIODIC MAINTENANCE SCHEDULE
13 MONTH 16 MONTH 19 MONTH 22 MONTH 25 MONTH 28 MONTH 31 MONTH
ITEM 13,000 16,000 19,000 22,000 25,000 28,000 31,000
ENGINE OIL R R R R R R R
OIL FILTER STRAINER C C C C
OIL TRANSMISSION R R R R
SPARK PLUG I & A R I & A R
AIR FILTER ELEMENT *
I & C I & C I & C I & C I & C R
CVT FILTER C C C C C C C
VALVE GAP I & A I & A
CARBURETTOR I & C I & C
CYLINDER HEAD / PISTON C & A
DRIVE BELT DAN CVT ROLLER I I R I
CLUTCH PLAY AT LEVER END I I
FUEL HOSE P I
FREENES THROTTLE CABLE I & A I & A I & A I & A I & A I & A I & A
STEERING PLAY I I I I I I I
R-REPLACE; C-CLEAN; I-INSPECT; A-ADJUST; L-LUBRICATE; T-TOP UP; S-SET TO TORQUE
PERIOD
Km
24
R
23
*AIR FILTER FOAM ELEMENT, PAPER ELEMENT, OIL COLLECTING ELEMENT.
