Tail lamp bulb
TVS DAZZ Tail lamp bulb can be replaced by
removing lens tail lamp. Removal procedure is as
follows:
1. Remove screws (2nos) from tail lamp
2. Take out the lens
3. Tail lamp bulb & turn signal lamps are
accessible
4. Replace the tail lamp bulb with a new one
5. Reverse the above procedure for reassembly.
MAINTENANCE
Always use the recommended light bulb
G
39
