TVS DAZZ User Manual

OVERALL DIMENSION   
Overall length 1855 mm
Overall width (Handle bar) 675 mm
Overall height 1075 mm
Seat height 750mm
Ground Clearance 150 mm
0
Gradeability 17
Wheel base 1240 mm
Dry Mass 92 Kg
Pay load 130 Kg  
ENGINE   
Type Single cylinder 4 stroke
air cooled engine
Bore x Stroke 53.5 x 48.8 mm
Piston displacement 109.65 cc
Compression ratio 9.5:1
Carburetor VM 17 UCAL  
SPECIFICATION
SPECIFICATION
1
1

TVS DAZZ Specifications

General

Displacement	109.7 cc
Brakes (Front)	Drum
Brakes (Rear)	Drum
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Gearbox	4-Speed
Max Torque	8.7 Nm @ 5500 rpm
