2. If the brake fluid is below the line of the leak
check and add if necessary.
3. When the braking feel soft and ineffective, it
may be due to the presence of air in the brake
system which need to be removed. Contact
authorized service centre for servicing brake
system.
Rear brake
1. Check the rear brake free play. Adjust the rear
brake to 15-20 mm.
Rear brake free play : 15 - 20 mm
2. To adjust the rear brake play, rotate the rear
brake adjusting nut clockwise or counter-
clockwise to get the appropriate play.
Check the oil level in the brake master cylinder
when the vehicle is an flat floor.
MAINTENANCE
33
15-20 mm
