TVS DAZZ User Manual

CHASSIS
Frame type Under Bone
0
Caster angle 26
Trail 87 mm
0
Steering angle 90
Brake front and rear
Front Disk 200 mm
Rear Drum 130 mm Dia
Tyre size
Front 80/90 - 14”
Rear 90/80 - 14”
Tyre pressure
2
Front 2.00 kg/cm (29 PSI)
2
Rear 2.25 kg/cm (32 PSI)
Suspension
Front Telescopic
Rear Toggle link, gas filled hydraulic dampers
SPECIFICATION
3

TVS DAZZ Specifications

General

Displacement	109.7 cc
Brakes (Front)	Drum
Brakes (Rear)	Drum
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Gearbox	4-Speed
Max Torque	8.7 Nm @ 5500 rpm
