http://www.TYAN.com
23
J47/J48/J49/J50/J56: 8-Pin FAN Connector
Pin 1 2 3 4
Signal
PWM VDD_12_RUN TACHIN GND
Pin 5 6 7 8
Pin_1
Signal
GND TACHIN VDD_12_RUN PWM
J50
J47
J49
J56
J48
