Chapter 1: Instruction
1.1 - Congratulations
You have purchased one of the most powerful server solutions based on the
Intel
®
Tylersburg chipset. The TYAN
®
S7002 series motherboard is designed to
support up to two Intel
®
Nehalem-EP 2S processors and up to 64GB DDR3-
800/1066/1333 memory. Leveraging the advanced technology from Intel, the
TYAN
®
S7002 series is capable of offering a scalable 32 and 64-bit computing
environment with high-bandwidth memory design and lightning-fast PCI-E bus
providing a rich feature set and incredible performance.
The TYAN S7002 series is designed around several different configurations
which are detailed in the following 1.2 Hardware Specification section:
1.2 - Hardware Specifications
TYAN S7002-LE (S7002G2NR-LE)
Supported CPU Series
Intel Xeon 5500 series QC/DC
processors
Socket Type / QTY LGA1366 / (2)
Thermal Design Power (TDP)
wattage
130W
Processor
System Bus (MHz) 1333/1066/800
IOH / ICH Intel 5500 / ICH10R
Chipset
Super I/O Winbond W83627
Supported DIMM Qty (8) DIMM sockets
DIMM Type / Speed DDR3 800/1066/1333 RDIMM, UDIMM
Capacity Up to 64GB
Memory channel 6 channels (3-channel per CPU)
Memory
Memory voltage 1.5V
PCI-E
(1) PCI-E x16 slot (Gen 2) / (2) PCI-E
x8 slots (w/ x4 link)
Expansion Slots
Recommended TYAN Riser
Card
M2083-RS, PCI-E x16 1U riser card
(left)
Port QTY (2)
LAN
Controller Intel 82574
Connector (6)
Controller ICH10R
Speed 3.0 Gb/s
Storage SATA
RAID S/W RAID 0,1,5,10 standard
