2.14 - Installing the Power Supply
There are three power connectors on your S7002.The S7002 supports EPS-
12V/SSI power supplies.
PWR2/3: 8-Pin EPS 12V PWR Connector
Signal Pin Pin Signal
GND
1 5
+12V2
GND
2 6
+12V2
GND
3 7
+12V3b
GND
4 8
+12V3b
PW1
PW3
PW2
