JP7 On Board SAS LSI1068E Enabled/Disabled
Pin_3 Pin_1
Pin 1 2 3
Pin_3 Pin_1
Signal
PLTRST# SAS_RST# GND
Note: Pin1-2: Enable onboard SAS chip;
Pin2-3: Disable onboard SAS chip
JP8/JP9: COM2 Select
Pin_3 Pin_1
Pin 1 2 3
Pin_3 Pin_1
Signal
SIO RX COM2_RX
BMC
RX
Note: Pin1-2: <Default>SIO to COM2;
Pin2-3: BMC UART2 to COM2
Onboard ID LED
You can identify the specific system using this LED. Users from
remote site could also activate ID LED by input a few commands in
IPMI, detailed software support please visit http://www.tyan.com
for
lastest AST2050 user guide.
Pin Signal
+ P3V3_AUX
- ID_SW_L
State Color Description
On Blue System identified
+ -
Off Off System not identified
