3.11.3 - Southbridge Configuration Sub-Menu
This menu gives options for southbridge devices settings. Select a
menu by highlighting it using the Arrow (/) keys and pressing Enter.
The settings are described on the following pages.
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
South Bridge Chipset Configuration
HAD Controller
SMBUS Controller
SLP_S4# Min. Assertion Width
Restore on AC Power Loss
[Enabled]
[Enabled]
[4 to 5 seconds]
[Power Off]
Options
Disabled
2 USB Ports
4 USB Ports
6 USB Ports
8 USB Ports
10 USB Ports
12 USB Ports
← → Select Screen
↑↓ Select item
+/- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Feature Option Description
South Bridge Chipset Configuration
Enabled
HAD Controller
Disabled
Enabled/Disabled SMBUS
HAD Controller
Disabled
SMBUS Controller
Enabled
Enabled/Disabled SMBUS
Controller
4 to 5
seconds
3 to 4 seconds
2 to 3 seconds
SLP_S4# Min. Assertion
Width
1 to 2 seconds
Set SLP_S4# Min. Assertion
Width.
Power Off
Power On
Restore on AC Power
Loss
Last State
System state after Restore on
AC Power Loss.
