9
I/O Shield (1) I/O Shield
Cable (6) SATA signal cables
Riser Card M2083-RS, PCI-E 1U riser card (left)
Optional
accessories for
future upgrade
Cable
(1) CCBL-0615, COM port cable / (1) CCBL-0311,
SATA 1-to-2 power cable / (1) CCBL-035J, USB
bracket cable
TYAN S7002 (S7002WGM2NR/S7002WGP2NR-LE)
Supported CPU Series
Intel Xeon 5500 series QC/DC processors
Socket Type / QTY LGA1366 / (2)
Thermal Design Power (TDP)
wattage
130W
Processor
System Bus (MHz) Intel QuickPath Interconnect (QPI)
IOH / ICH Intel 5520 / ICH10R
Chipset
Super I/O Winbond W83627
Supported DIMM Qty (8) DIMM sockets
DIMM Type / Speed DDR3 800/1066/1333 RDIMM, UDIMM
Capacity Up to 64GB
Memory channel 6 channels (3-channel per CPU)
Memory
Memory voltage 1.5V
PCI-E
(1) PCI-E x8 slot (w/ x4 link) / (1) PCI-E
x16 slot (Gen 2) / (2) PCI-E x8 slots (Gen
2)
Expansion
Slots
Recommended TYAN Riser
Card
M2083-RS, PCI-E x16 1U riser card (left)
Port QTY (2)
LAN
Controller Intel 82574
Connector (8)
Controller LSI SAS1068E
Speed 3.0 Gb/s
SAS
RAID S/W RAID 0,1,1E standard
Connector (6)
Controller ICH10R
Speed 3.0 Gb/s
Storage
SATA
RAID S/W RAID 0,1,5,10 standard
