Motherboard Components
Connectors
1. Dedicated IPMI port+ USB3.0x2 (J112)
20. BMC Heartbeat LED (BMC_LED4)
2. SSATA Connector 4 (SSATA4)
21. PCH_SATA_RAID_KEY (J51)
3. VGA+COM Connector (VGA_COM1)
22. Front Panel Header (FPIO_1)
4. SSATA Connector 5 (SSATA5)
23. Reset Button (RST_ BTN1)
5. LAN Connector (LAN2)
24. Power Button (PWR_BTN1)
6. LAN Connector (LAN1)
25.IPMB Pin Header (IPMB_HD1)
7. Clear CMOS Button (CLEAR_BTN1)
26. M.2 NGFF PCIe 22x42/60/80mm Socket
(U58)
8. Vertical Type A USB Connector
(TYPEA_USB3)
27. CPU1 FAN Header (CPU1_FAN)
9. Rear ID LED Button(ID LED_BTN1)
28. SYS_FAN2 Header( SYS_FAN_2)
10. VGA Header (FPIO_VGA3)
29. SSI 8-pin CPU1 Power Connector (PW2)
11. Rear ID LED (ID_LED1)
30. SSI 8-pin CPU0 Power Connector (PW1)
12. TYAN Module Header (DBG_HD1)
31. CPU0 PVCCP POWER OK LED
(P0_PG_LED1)
13. Front Panel USB3.0 Header (USB3_FPIO1)
32. SYS_FAN 1 Header (SYS_FAN_1)
14. Rear IO_FAN 2 (SYS_FAN_3)
33. CPU0 FAN Header (CPU0_FAN)
15. Internal USB2.0 Header (J26)
34. ATX Power Connector (24 pin) (PWR1)
16. sSATA SGPIO Header for SSATA4/SSATA5
(SSATA_SGPIO1)
35. PSMI Pin Header (PSMI_HD1)
17. COM2 Header (HD_COM2)
36. 36-pin Vertical Mini SAS HD Connector
(SATA 3.0 signals)(PCH_SSATA_0123)
18. FAN Tachometer Header (FAN_HD1)
37. 36-pin Vertical Mini SAS HD Connector
(SATA 3.0 signals)(PCH_SATA_0123)
19. On board BMC IPMI ALERT LED
(IPMI_LED1)
38. 36-pin Vertical Mini SAS HD Connector
(SATA 3.0 signals) (PCH_SATA_4567)
Headers/Jumpers
a. ME Recovery Mode Jumper (J113)
d. PSU Throttling Jumper (J125)
b. BMC COM PORT Jumper (J119)
e. PC BEEP Jumper (J120)
c. BMC COM PORT Jumper (J118)
PCIE Slots
A+C. OCP 2.0 PCI-E Gen3x16 MEZZ slot
f/CPU0 for LAN Card
F+G. OCP 2.0 PCI-E Gen3x16 MEZZ slot
f/CPU1 for LAN card
Standalone C. OCP 1.0 PCI-E Gen3x8 MEZZ
slot f/CPU0 for LAN Card
StandaloneG.OCP 1.0 PCI-E Gen3x8 MEZZ slot
f/CPU1 for LAN card
B. OCP 2.0 KR interface(only available in
S7106GM2NR-L2 SKU)
D PCI-E Gen3x24 slot(x24 link) f/ CPU1
E. PCI-E Gen3x24 slot(x24 link) f/ CPU0
Memory Slots
H. CPU0 Memory Slot (P0_MC0_DIM_CH_C0)
P CPU1 Memory Slot (P1_MC0_DIM_CH_C0)
I. CPU0 Memory Slot (P0_MC0_DIM_CH_B0)
Q CPU1 Memory Slot (P1_MC0_DIM_CH_B0)
