Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S7106 motherboard, based on the Intel
®
C621/C622 Lewisburg chipset. The S7106 is designed to support Intel
®
Xeon
®
Skylake Scalable Processor Families, and Up to 512GB RDIMM/ 1024GB
LRDIMM/ 768GB LRDIMM 3DS* DDR4 memory. Leveraging advanced technology
from Intel
®
, the S7106 is capable of offering scalable 32 and 64-bit computing, high-
bandwidth memory design, and lightning-fast PCI-E bus implementation.
The S7106 not only empowers you in today‟s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S7106 with the power and flexibility to meet demanding
requirements for today‟s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can find
all the information on all TYAN
®
products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
S7106GM2NR
Processor
Socket Type / Q'ty
LGA3647/ (2)
Supported CPU
Series
Intel Xeon Skylake Scalable
Processor Families
Thermal Design
Power (TDP)
wattage
Max up to 205W
Chipset
PCH
S7106GM2NR Intel C621
Memory
Supported DIMM
Qty
(8)+(8) DIMM slots
DIMM Type /
Speed
DDR4 RDIMM/RDIMM
3DS/LRDIMM/LRDIMM 3DS 2666
Capacity
Up to 512GB RDIMM/ 1,024GB
LRDIMM/ 768GB LRDIMM 3DS
*Follow latest Intel DDR4 Memory
POR
Memory channel
6 Channels per CPU
Memory voltage
1.2V
