TYAN S7106 - Expansion Slots

http://www.tyan.com
5
Expansion Slots
PCI-E
(2) PCI-E Gen3 x24 slots
Others:
(2) PCI-E Gen3 x16 OCP 2.0 slots
(con.A+con.C or con.F+con.G)
(1) PCI-E Gen3 x2 for M.2 Port
(2242/2260/2280)
LAN
Port Q'ty
(2) GbE ports, (1) PHY dedicated
for IPMI
Controller
Intel I210-AT
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) Mini-SAS HD (8-ports)
Controller
Intel C621
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
M.2
connector
(1) M.2 connector
(2242/2260/2280)
by PCI-E
interface
sSATA
Connector
(1) Mini-SAS HD (4-ports)
+ (2) SATA-III
Controller
Intel C621
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe) only for 4 SATA
devices
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
Input /Output
USB
(2) USB3.0 ports (via cable), (2)
USB3.0 ports (at rear), (2) USB 2.0
ports (via cable), (1) Type-A
USB3.0 port
COM
(2) ports (1 at rear, 1 via cable)
VGA
(2) D-Sub ports (1 at rear, 1 via
cable)
RJ-45
(2) GbE ports, (1) Dedicated for
IPMI
Front Panel
(1) 2x12-pin SSI front panel header
SATA
(2) SATA-III connectors + (3) Mini-
