7
Operating System
OS supported list
Please refer to our Intel OS
supported list.
Package Contains
Motherboard
(1) S7106 Motherboard
Manual
(1) Web User's manual, (1) Quick
Installation Guide
Installation CD
(1) TYAN installation CD
S7106GM2NR-L2 Specifications
Processor
Socket Type / Q'ty
LGA3647/ (2)
Supported CPU
Series
Intel Xeon Skylake Scalable
Processor Families
Thermal Design
Power (TDP)
wattage
Max up to 205W
Chipset
PCH
Intel C622
Memory
Supported DIMM
Qty
(8)+(8) DIMM slots
DIMM Type /
Speed
DDR4 RDIMM/RDIMM
3DS/LRDIMM/LRDIMM 3DS 2666
Capacity
Up to 512GB RDIMM/ 1,024GB
LRDIMM/ 2,048GB LRDIMM 3DS
*Follow latest Intel DDR4 Memory
POR
Memory channel
6 Channels per CPU
Memory voltage
1.2V
Expansion Slots
PCI-E
(2) PCI-E Gen3 x24 slots
Others:
(2) PCI-E Gen3 x16 OCP 2.0 slots
(con.A+con.C or con.F+con.G)
(1) PCI-E Gen3 x2 for M.2 Port
(2242/2260/2280)
LAN
Port Q'ty
(2) GbE ports, (1) PHY dedicated for
IPMI
Controller
Intel I210-AT
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) Mini-SAS
HD (8-ports)
Controller
Intel C622
Speed
6.0 Gb/s
