8
RAID
RAID 0/1/10/5
(Intel RSTe)
M.2
connector
(1) M.2 connector
(2242/2260/2280) by
PCI-E interface
sSATA
Connector
(2) SATA-III, (1)
Mini-SAS HD
(4-ports)
Controller
Intel C622
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5
(Intel RSTe)
only for 4 SATA
devices
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
Input /Output
USB
(2) USB3.0 ports ( via cable), (2)
USB3.0 ports (at rear), (2) USB 2.0
ports (via cable), (1) Type-A USB3.0
port
COM
(2) Ports (1 at rear, 1 via cable)
VGA
(2) D-Sub ports (1 at rear, 1 via
cable)
RJ-45
(2) GbE ports, (1) Dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
SATA
(2) SATA-III connectors + (3) Mini-
SAS HD (4-in-1) connectors
Power
(1) ATX 24-pin + (2) 8-pin power
connectors
Others
(1) UID button
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (5) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
