6
SAS HD (4-in-1) connectors
Power
(1) ATX 24-pin + (2) 8-pin power
connectors
Others
(1) UID button
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (5) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Over temperature warning indicator,
Fan & PSU fail LED indicator
Others
Watchdog timer support
Server Management
AST2500 iKVM
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
Supports storage over IP and
remote platform-flash, USB 2.0
virtual hub
AST2500 IPMI
Feature
24-bit high quality video
compression, 10/100/1000 Mb/s
MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
PXE boot support, ACPI 5.0,
SMBIOS 3.0/PnP/Wake on LAN,
ACPI sleeping states S4,S5, User-
configurable H/W monitoring
Physical Dimension
Form Factor
EATX
Board Dimension
12"x13" (305x330mm)
Regulation
FCC (DoC)
Class B
CE (DoC)
Yes
Operating Environment
Operating Temp.
10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp.
- 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Compliant
Yes
