TYAN S7106 - Page 49

http://www.tyan.com
49
3.3.5 Onboard Device Configuration
Onboard VGA
Enable/Disable ASPEED VGA
Disabled / Enabled
ICC Clock Spread Spectrum
Turn on / off Spread Spectrum Setting for IsCLK.
Enabled / Disabled
Onboard Lan I210
Enable/Disable Onboard Lan I210
Disabled / Enabled
Chassis Intrusion detect
Enabled: When a chassis open event is detected, the BIOS will record the event.
Disabled / Enabled
NMI Button
Enable or disable NMI button.
Disabled / Enabled
