20
PWR_BTN1: POWER Button
Pin
1
2
3
4
Signal
GND
GND
PWR_BTN1
PWR_BTN1
RST_BTN1: COLD Reset Button
Pin
1
2
3
4
Signal
GND
GND
FP_RST_BTN_N
FP_RST_BTN_N
PJ1: SMBus Connector
Signal
Pin
Pin
Signal
SMB CLK
1
2
SMB DATA
GND
3
J9: J1 NVMe or SATA Select Jumper
Signal
Pin
Pin
Signal
VDD_33_RUN
1
2
VDD_33_RUN
J1_SATA_NVME#
3
4
J2_SATA_NVME#
GND
5
6
GND
1-3: J1 (SlimSAS1) NVME SMBUS
3-5: J1 (SlimSAS1) SATA SGPIO
J9: J2 NVMe or SATA Select Jumper
Signal
Pin
Pin
Signal
VDD_33_RUN
1
2
VDD_33_RUN
J1_SATA_NVME#
3
4
J2_SATA_NVME#
GND
5
6
GND
2-4: J2 (SlimSAS2) NVME SMBUS
4-6: J2 (SlimSAS2) SATA SGPIO
J190/J191: BMC COM PORT2 (RX/TX) Jumper
Signal
Pin
Pin
Signal
BMC_COM_TXD/
BMC_COM_RXD
1
2
TXD_OUT/RXD_OUT
BMC_TXD5
BMC_RXD5
3
1-2 : BMC COM PORT2 (DEFAULT)
2-3 : BMC CONSOLE PORT5
