TFP610
Page 12 of 28
7'-6" (2,3 m) MAX. HORIZONTAL
HIP
RIDGES
6'-0" (1,8 m) MAX.
3'-0" (0,9 m) MIN.
SEE FIG. 11
3'-0" (0,9 m)
MAX. ON
OUTSIDE
WALL
MAXIMUM
28'-0" (8,5 m)
RIDGE LINE
RAFTERS IN HIP SLOPE
AREA PERPENDICULAR
TO OUTSIDE WALL
ROOF
SLOPE
HIP
SLOPE
HIP SPRINKLERS
PROTECT AREA ON
BOTH SIDES OF
HIP RIDGE
SEE FIG. 11
BACK
TO BACK
HIP RIDGES
OUTSIDE WALL
6'-0" (1,8 m) MAX.6'-0" (1,8 m) MAX.
CPVC PIPE MAY BE USED IN SHADED AREA ONLY
FOR CEILING PROTECTION BELOW (SEE PAGE 6)
WHERE AN AREA
(SHOWN NON-SHADED)
IS PROTECTED
WITH AP SPRINKLERS,
CPVC MAY BE
USED FOR CEILING
PROTECTION BELOW
(SEE PAGE 6)
HIP
SLOPE
RIDGE LINE
ROOF
SLOPE
BACK
TO BACK
SPRINKLERS
TRUSSES IN HIP SLOPE AREA
PARALLEL TO OUTSIDE WALL
STANDARD SPRAY
SPRINKLERS INSTALLED
PER NFPA 13 IN HIP SLOPE
AREA WHEN TRUSSES
ARE FRAMED PARALLEL
TO OUTSIDE WALL
SINGLE
DIRECTIONAL
SPRINKLERS
MAXIMUM
40'-0" (12,2 m)
HORIZONTAL
ROOF SPAN
(COVERAGE)
3'-0" (0,9 m)
MAX. ON
HIP SLOPE
3'-0" (0,9 m)
MAX. ON
HIP SLOPE
CPVC PIPE MAY BE USED IN SHADED AREA ONLY
FOR CEILING PROTECTION BELOW (SEE PAGE 6)
WHERE AN AREA
(SHOWN NON-SHADED)
IS PROTECTED
WITH AP SPRINKLERS,
CPVC MAY BE
USED FOR CEILING
PROTECTION BELOW
(SEE PAGE 6)
HIP
SLOPE
RIDGE LINE
ROOF
SLOPE
BACK
TO BACK
SPRINKLERS
TRUSSES IN HIP SLOPE AREA
PARALLEL TO OUTSIDE WALL
6'-0" (1,8 m) MAX.
STANDARD SPRAY
SPRINKLERS INSTALLED
PER NFPA 13 IN HIP SLOPE
AREA WHEN TRUSSES
ARE FRAMED PARALLEL
TO OUTSIDE WALL
OUTSIDE WALL
FIGURE 12
HIP ROOF INSTALLATION
WITH RAFTERS FRAMED
PERPENDICULAR TO
OUTSIDE WALL
(SHOWN WITH HIP
SPRINKLERS PROTECTING
HIP SLOPE & ADJACENT
AREAS TO HIP SLOPE)
FIGURE 13A
HIP ROOF INSTALLATION
WITH TRUSSES FRAMED
PARALLEL TO OUTSIDE WALL
(SHOWN WITH STANDARD
SPRAY OR AP SPRINKLERS IN
HIP SLOPE)
FIGURE 13B
HIP ROOF INSTALLATION
WITH TRUSSES FRAMED
PARALLEL TO OUTSIDE WALL
(SHOWN WITH STANDARD
SPRAY OR AP SPRINKLERS
IN HIP SLOPE & ADJACENT
AREAS TO HIP SLOPE)
