Tyco CC3 User Manual

TFP633
Page 6 of 8
UPPER
DECK
MODEL CC3
SPRINKLER
CEILING
FRAMING
84" (2134 mm)
MAXIMUM
TOP CHORD GREATER
THAN 4" (102 mm) IN DEPTH
FRAME ARMS OF SPRINKLER
MUST BE INSTALLED
IN-LINE WITH PIPE RUN
1-1/2" (38 mm)
MINIMUM
2" (51 mm)
MAXIMUM
CEILING
60" (1524 mm) MAXIMUM
6" (152 mm) MINIMUM
FRAME ARMS OF SPRINKLER
MUST BE INSTALLED
IN-LINE WITH PIPE RUN
UPPER
DECK
MODEL CC3
SPRINKLER
2x FLOOR SOLID
WOOD JOISTS
NON-COMBUSTIBLE
INSULATION
COMPOSITE
WOOD JOISTS
4" (102 mm)
MAXIMUM
1-1/2" (38 mm)
MINIMUM
84" (2134 mm)
MAXIMUM
CEILING
FRAMING
CEILING
60" (1524 mm) MAXIMUM
6" (152 mm) MINIMUM
FIGURE 7
NON-COMBUSTIBLE INSULATION-FILLED UPPER DECK SOLID WOOD OR COMPOSITE WOOD JOIST
CONSTRUCTION CROSS SECTION ELEVATION VIEW
STEEL PIPE
FIGURE 8
OBSTRUCTED WOOD TRUSS CONSTRUCTION CROSS SECTION ELEVATION VIEW
STEEL PIPE
