Care and
Maintenance
The TYCO FASTFLEX Flexible Sprinkler
Hose must be maintained and serviced
in accordance with this section.
Before closing a fire protection system
control valve for inspection or main-
tenance work on the fire protection
system that it controls, permission to
shut down the effected fire protection
system must first be obtained from
the proper authorities and all person-
nel who may be affected by this action
must be notified.
After placing a fire protection system
in service, notify the proper authorities
and advise those responsible for moni-
toring proprietary and/or central station
alarms.
The owner is responsible for the inspec-
tion, testing, and maintenance of their
fire protection system and devices in
compliance with this document, as well
as with the applicable standards of the
authorities having jurisdiction. Contact
the installing contractor or product
manufacturer with any questions.
Automatic sprinkler systems are rec-
ommended to be inspected, tested,
and maintained by a qualified Inspec-
tion Service in accordance with local
requirements and/or national codes.
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indicate
the full product name and Part Number
(P/N).
Flexible Hose Assembly
The FASTFLEX Flexible Hose
Assembly includes Flexible Hose,
ISO 7-R 1 x Hose Thread Inlet Nipple,
1/2" NPT x Hose Thread Straight Sprin-
kler Reducer, Reducer Bracket, Bar
Fixing Clamps, and Support Bar.
Note: Refer to Table A for Model, Type,
Length, Bar Fixing Clamp options, and
Approval details.
Specify: Model (specify) FASTFLEX
Flexible Sprinkler Hose Assembly, Type
(specify), (specify) length, (specify) Bar
Fixing Clamp, P/N (specify):
Model YN25, Un-braided, 50 mm Clamps
700 . . . . . . . . . . . . . . . . . . . . . . . . . . . YN250700
1000 .......................... YN251000
1200 .......................... YN251200
1500 .......................... YN251500
1800 . . . . . . . . . . . . . . . . . . . . . . . . . . YN251800
2000 .......................... YN252000
2500 .......................... YN252500
2700 . . . . . . . . . . . . . . . . . . . . . . . . . . YN252700
3100 .......................... YN253100
3700 .......................... YN253700
Model YN25, Un-braided, 90 mm Clamps
700 . . . . . . . . . . . . . . . . . . . . . . . . . . YN250700C
1000 .........................YN251000C
1200 .........................YN251200C
1500 .........................YN251500C
1800 . . . . . . . . . . . . . . . . . . . . . . . . . YN251800C
2000 .........................YN252000C
2500 .........................YN252500C
2700 . . . . . . . . . . . . . . . . . . . . . . . . . YN252700C
3100 .........................YN253100C
3700 .........................YN253700C
Model YB25, Braided, 50 mm Clamps
700 . . . . . . . . . . . . . . . . . . . . . . . . . . . YB250700
1000 ...........................YB251000
1200 ...........................YB251200
1500 ...........................YB251500
1800 . . . . . . . . . . . . . . . . . . . . . . . . . . .YB251800
2000 .......................... YB252000
2500 .......................... YB252500
Model YB25, Braided, FM Approved
50 mm Clamps
700 . . . . . . . . . . . . . . . . . . . . . . . . . .YB250700-F
1000 .........................YB251000-F
1200 .........................YB251200-F
1500 .........................YB251500-F
1800 . . . . . . . . . . . . . . . . . . . . . . . . . YB251800-F
Model YB28, Braided, 50 mm Clamps
700 . . . . . . . . . . . . . . . . . . . . . . . . . . . YB280700
1000 .......................... YB281000
1200 ...........................YB281200
1500 ...........................YB281500
1800 . . . . . . . . . . . . . . . . . . . . . . . . . . .YB281800
2000 .......................... YB282000
2500 .......................... YB282500
Model YB28, Braided, FM Approved,
50 mm Clamps
700 . . . . . . . . . . . . . . . . . . . . . . . . . .YB280700-F
1000 .........................YB281000-F
1200 .........................YB281200-F
1500 .........................YB281500-F
1800 . . . . . . . . . . . . . . . . . . . . . . . . .YB281800-F
Accessories
Inlet Nipple
Specify: (25 mm or 28 mm) hose thread
FASTFLEX Inlet Nipple with (ISO 7-R 1
or ISO 7-R 1 1/4) inlet thread connec-
tion, P/N (specify):
25 mm Hose Thread
ISO 7-R 1 ...................HOSENIP25
ISO 7-R 1 1/4 .............. HOSENIP25R
28 mm Hose Thread
ISO 7-R 1 . . . . . . . . . . . . . . . . . . .HOSENIP28
ISO 7-R 1 1/4 . . . . . . . . . . . . . . HOSENIP28R
Sprinkler Reducer
Specify: (Straight, 45 Degree, or 90
Degree) for (25 mm or 28 mm hose
threads) FASTFLEX Sprinkler Reducer
with (ISO 7-Rc 3/8, 1/2 inch NPT, or 3/4
inch NPT) outlet thread connection,
P/N (specify):
Straight
25 mm Hose Thread
ISO 7-Rc 3/8 ...................PBR120
1/2 inch NPT ...................RBR120
3/4 inch NPT ...................SBR120
28 mm Hose Thread
ISO 7-Rc 3/8 .................PBR28120
1/2 inch NPT .................RBR28120
3/4 inch NPT .................SBR28120
45 Degree
25 mm Hose Thread
ISO 7-Rc 3/8 ...................PBAR45
1/2 inch NPT ...................RBAR45
3/4 inch NPT ...................SBAR45
28 mm Hose Thread
ISO 7-Rc 3/8 .................PB28AR45
1/2 inch NPT .................RB28AR45
3/4 inch NPT .................SB28AR45
90 Degree
25 mm Hose Thread
ISO 7-Rc 3/8 ...................PBAR90
1/2 inch NPT ...................RBAR90
3/4 inch NPT ...................SBAR90
28 mm Hose Thread
ISO 7-Rc 3/8 .................PB28AR90
1/2 inch NPT .................RB28AR90
3/4 inch NPT .................SB28AR90
90 Degree Short Radius
(LPCB Approved Only)
25 mm Hose Thread
1/2 inch NPT . . . . . . . . . . . . . . . . . RBAR90S
28 mm Hose Thread
1/2 inch NPT ............... RB28AR90S
Bar Fixing Clamps
Specify: FASTFLEX (50 mm or 90 mm)
Bar Fixing Clamps, P/N (specify):
50 mm .......................... RBF58T
90 mm .......................... RBF90T
