Electrical| Operating Voltage | 24 V |
|---|---|
| Quiescent Current | 25 mA |
| Alarm Current | 80 mA max. |
| Beam Length | 2 to 30 Metres |
Mechanical| Dimensions | W165 x H125 x D165 mm |
|---|---|
| Weight | 0.96 kg |
| Material | Noryl GTX Grade 810 |
Environmental| Operating Temperature | -10 to +55°C |
|---|---|
| Housing Protection | IP65 |
| BASEEFA certification | Eex ib IIB T5 |
Electrical| Power Consumption | 24 V dc ±20% |
|---|---|
| Quiescent | 100 mA |
| Alarm/Fault | 130 mA |
| Detector Supply | up to 80 mA |
| Alarm Contacts | 24 V 1A (NO Volt Free) |
Mechanical| Dimensions | W100 x H70 x D112 mm |
|---|---|
| Weight | 0.28 kg |
| Material | Light-grey Polycarbonate |
Environmental| Operating Temperature | 0 to +55°C |
|---|---|
| Storage Temperature | -10 to +60°C |
| Humidity | 0 to 90% RH (non-condensing) |
