The right is reserved to modify or withdraw any product or service without notice. Issue – 1. Dec 2017 © 2017
Technical Sales Support / Oil & Gas - Detection & Control
Johnson Controls
Grimshaw Lane, Manchester, M40 2WL, UK
Sales
Tel: +44 (0)161 455 4243
Email: mpinkerton@tycoint.com
Technical Support
Tel: +44 (0)161 455 4558
Email: rhughes@tycoint.com
8. Maintenance
Every 3 months clean the detector lenses and the reflector using warm water and a mild detergent. Dry and polish with a clean
soft non-abrasive cloth.
Every 3 months after cleaning the detector lenses and reflector test the system using the commissioning procedure as specified in
section 6 of this manual.
9. Specification
9.1 Detector
Electrical
Operating Voltage: 24 V (via P-UIM)
Quiescent Current: 25 mA
Alarm Current: 80 mA max.
Beam Length: 2 to 30 Metres
Mechanical
Dimensions: W165 x H125 x D165 mm
Weight: 0.96 kg
Material: Noryl GTX Grade 810
Environmental
Operating Temperature: -10 to +55
0
C
Housing Protection: IP65
BASEEFA certification: Eex ib IIB T5
9.2 P-UIM
Electrical
Operating Voltage:
Power Consumption: 24 V dc ±20%
Quiescent: 100 mA
Alarm/Fault: 130 mA
Detector Supply: up to 80 mA
Alarm Contacts: 24 V 1A (NO Volt Free)
Fault Contact: 24 V 1A (NC Volt Free)
Energised = Healthy
De-energised = Fault
Contacts can be re-configured to customer requirements
upon request.
Mechanical
Dimensions: W100 x H70 x D112 mm
Weight: 0.28 kg
Material: Light-grey Polycarbonate
Environmental
Operating Temperature: 0 to +55
0
C
Storage Temperature: -10 to +60
0
C
Humidity: 0 to 90% RH (non-condensing)
12 / 12
