MM-012099-001
73
9.16 MENU
The Menu function accesses features that are not available directly from the keypad. The order and actual
menu items available is configurable through programming. At radio power up, the menu item that is at
the top of the menu list will always be displayed first. Subsequent access to the menu function will return
the last menu item that was shown in the display and cursor position.
1. To enter the menu mode, press the
key.
2. Upon entering the menu selection mode, Menu options will appear in the display (see Figure 9-6).
Figure 9-6: Menu Display
3. The radio will continue to receive and transmit normally while in the menu function.
4. To scroll through the menu options use the
or keys. When the required menu item has been
found align the cursor with the option then press
to select it. The menu item's parameter setting
shown in the display can now be changed by using
or to scroll through the list of parameter
values.
5. Once the desired setting is reached press
to store the value and return the menu option selection
level.
6. For menu items that display radio information, pressing
or will scroll through a list of
informational displays. The possible menu items are in Table 9-3.
9.16.1 Menu Item Selection Process
An example of the menu item selection process and menu item parameter change is shown in Figure 9-7
for the backlight menu item.
1. Press
to enter the menu mode.
2. Press
or until the display shows:
Figure 9-7: Backlight Menu Item Parameter
