PRODUCT DETAILS
Item Description
1 Hose
2 Adapter Ring
3 Seal
4 Nut
5 Nipple
6 Braid
7 Collar
Series AQB Flexible Hose – Braided (1" nominal diameter)
Item Description
1 Hose
2 Adapter Ring
3 Seal
4 Nut
5 Nipple
Series AQU Flexible Hose – Unbraided (
7
⁄8" nominal diameter)
1
4
2
3
5
2¼
7
7
6
1
4
2
3
5
2¼
5.5" straight reducer
9.0" straight reducer
13.0" straight reducer
Short 90° elbow reducer
Long 90° elbow reducer
10.85_3
AquaFlex
®
Stainless Steel
Sprinkler Fittings
10.85
FIRE PROTECTION PRODUCTS – ACCESSORIES
