Ordering
Procedure
When placing an order, indicate thefull
product name. Refer to the Price List
for complete listing of Part Numbers.
NOTE
Sprinklers, wrenches, guards, shields,
attachment springs, and additional clip
installation tool are all sold separately
Contact your local distributor for avail-
ability.
Sprinklers:
Specify: (Specify Model/SIN), (Specify
Standard Response, Special Re-
sponse, or Quick Response, (specify
K-factor), (specify temperature rating),
(specify Pendent or Upright) Sprinkler,
P/N (specify from Table A).
Sprinkler Wrenches:
Specify: W-Type (specify) Sprinkler
Wrench, P/N (specify).
W-6. . . . . . . . . . . . . . . . . . . . . P/N 56-000-6-387
W-7. . . . . . . . . . . . . . . . . . . . . P/N 56-850-4-001
Guards:
Specify: Model G-1 Guard having
(specify) finish, P/N (specify).
Red Painted . . . . . . . . . . . . . . P/N 56-000-6-387
Zinc Chromate . . . . . . . . . . . . P/N 56-850-4-001
Shields:
Specify: Model (specify), (specify NPT
size) Shield , P/N (specify).
H1, 1/2" NPT . . . . . . . . . . . . . P/N 22521
H1, 3/4" NPT . . . . . . . . . . . . . P/N 22522
H2, 1/2" NPT . . . . . . . . . . . . . P/N 22529
H2, 3/4" NPT . . . . . . . . . . . . . P/N 22524
Attachment Springs:
Specify: (specify NPT size) Shield
Spring, P/N (specify).
1/2" NPT . . . . . . . . . . . . . . . . . P/N 22526
3/4" NPT . . . . . . . . . . . . . . . . . P/N 22527
Additional* Clip Installation Tools:
specify: Clip Installation Tool for G1
Guard, P/N 56-000-8-597.
* The Clip Installation Tool is included
with guard orders in original cartons.
P/N 51 — XXX — 1 — XXX
68°C (Red)155
TEMPERATURE
RATING
(Fluid Color)
57°C (Orange)1351
SPRINKLER
MATERIAL
TABLE A
PART NUMBER SELECTION
FLAT SPRAY SPRINKLERS
79°C (Yellow)
286
93°C (Green)200
141°C (Blue)
175
NATURAL BRASS
MODEL/SIN
391 115K PENDENT, 3/4 INCH NPT
382 57K PENDENT, ISO 7/1-R 3/8
370 80K UPRIGHT, 1/2 INCH NPT
TY-FRFS/TY1236
TY-FRFS/TY3136
TY-FRFS/TY4236
371
390
80K PENDENT, 1/2 INCH NPT
115K UPRIGHT, 3/4 INCH NPT
TY-FRFS/TY3236
TY-FRFS/TY4136
482 57K PENDENT, ISO 7/1-R 3/8TY-FS Special/TY1246
470 80K UPRIGHT, 1/2 INCH NPTTY-FS Special/TY3146
471 80K PENDENT, 1/2 INCH NPTTY-FS Special/TY3246
490 115K UPRIGHT, 3/4 INCH NPTTY-FS Special/TY4146
491 115K PENDENT, 3/4 INCH NPTTY-FS Special/TY4246
582 57K PENDENT, ISO 7/1-R 3/8TY-FS/TY1256
570 80K UPRIGHT, 1/2 INCH NPTTY-FS/TY3156
571 80K PENDENT, 1/2 INCH NPTTY-FS/TY3256
590 115K UPRIGHT, 3/4 INCH NPTTY-FS/TY4156
591 115K PENDENT, 3/4 INCH NPTTY-FS/TY4256
380 TY-FRFS/TY1136 57K UPRIGHT, ISO 7/1-R 3/8
480 TY-FS Special/TY1146 57K UPRIGHT, ISO 7/1-R 3/8
580 TY-FS/TY1156 57K UPRIGHT, ISO 7/1-R 3/8
TFP635
Page9of10
