TYCROP SMOOTHFLOW - Rear Step Ladder

16
Rear Step Ladder
CAUTION
Only use grab handle when the passenger side door is
secured open (Figure 06 - 3).
Figure 06 - 3
The rear step ladder is located on the rear passenger side
corner above the light bar (Figure 07 - 3).
Figure 07 - 3
1. Pull the rear step ladder out until it is fully extended (Figure
08 - 3) and lower it (Figure 09 - 3).
Figure 08 - 3
Figure 09 - 3
2. When climbing the ladder, use the grab handle located on
the passenger side rear door post (Figure 06 - 3).
3. To stow the ladder, lift the rear step ladder (Figure 10 - 3)
and push it in until the clasp is fully engaged around the
bar (Figure 11 - 3).
Figure 10 - 3
Figure 11 - 3
Ladder and Platform - 3
