Operator’s Manual | Moving Floor Trailer 17
Option: Manual
Roll Tarp
Opening Tarp
1. Remove tarp securements, e.g. bungee cords (Figure 01
- 4), straps if equipped (Figure 02 - 4), and cinches and
cables if equipped (Figure 03 - 4), along the driver side of
the trailer. Cinches should be hung on nearby hooks to
avoid damaging the trailer. (Figure 03 - 4).
Figure 01 - 4
Figure 02 - 4
Figure 03 - 4
CAUTION
The tarp securements are under tension.
2. Climb front ladder (Figure 04 - 4). (Refer to Front Ladder
and Platform on page 15)
Figure 04 - 4
3. From the platform, roll the tarp up using the crank handle
(Figure 05 - 4), which is located in the holder on the front
wall beside the ladder. Insert the square end of the crank
handle into tarp tube. (Figure 06 - 4). Once the tarp is
rolled up against the tarp stops (Figure 07 - 4), stow the
tarp crank handle in the holder.
Figure 05 - 4
Figure 06 - 4
Figure 07 - 4
Option: Manual Roll Tarp - 4
