Operator’s Manual | Moving Floor Trailer 31
Option: Barn
Doors
DANGER
Depending on the material being hauled, the load can
potentially settle and put extreme pressure on the rear
doors. Use caution - the door may burst open when
opening.
Opening Barn Doors
1. Release the latch (Figure 01 - 8) on the passenger side
barn door and open the door. Secure the door open using
the spring latch (Figure 02 - 8) on the rear side corner of
the trailer.
Figure 01 - 8
Figure 02 - 8
2. Release the latch (Figure 03 - 8) on the driver side barn
door and open the door. Secure the door open using the
spring latch (Figure 04 - 8) on the rear corner of the trailer.
Figure 03 - 8
Figure 04 - 8
Closing Barn Doors
1. Remove the spring latch which is holding the driver side
barn door open and stow it (Figure 05 - 8). Close and
secure the door using the handle (Figure 06 - 8).
Figure 05 - 8
Figure 06 - 8
Option: Barn Doors - 8
