SECTION 2. SPECIFICATIONS
1) GEAR PUMP
MODEL T233HST / T273HST
Delivery (cc/rev) 3.7
Pump performance
150
(kgf/cm
2
)
1000 rpm 3.2 LPM
1800 rpm 6.0 LPM
2600 rpm 8.9 LPM
Maximum pressure (kgf/cm
2
) 125
Rated operation speed (rpm) 800~3000
Rotation direction C.W as viewed from shaft end
2. Power steering valve Unit(orbitrol)
MODEL T233HST / T273HST
Displacement (cc/rev) 63
Rated flow (ℓ/min) 16
Maximum system pressure (kgf/cm
2
) 125
Max. back pressure (kgf/cm
2
) 20
Max. temperature(℃) 95
Input torque (kgf.m) 0.1~0.2
Inlet relief pressure setting (kgf/cm
2
) 110~115 (at 12 ℓ/min)
Recommended filter Nominal 10 micron
3. OIL TANK
MODEL T233HST / T273HST
TANK TRANS MISSION
Fluid volume (ℓ) 17
Fluid THF500
8-2
