SECTION 2. COMPONENT LOCATION
1.Hydraulic Hoses and lines.
③
④
⑤
1. hydraulic oil cooler 2. Gear pump 3. Cooler return Line 4. Loader Valve
5. Power steering Unit
4-3
①
②
