Maximum flow
(
ℓ
/min)
45 LPM
Maximum pressure(Kg
f/
㎠
)
210
A
and B port leak
Oil temperature:50
℃
(122
℉
)
Under a load of 100Kgf/
㎠
9 cc/min below
Recommended fluid
THF 500
Operating temperature
range
-
20
℃
~80
℃
4. SPECI
FICA
TI
ONS
9-18
4.1 HYDRAUL
IC
CIRCUI
T
Fig. 9-33 Remote hy
draulic
pump
P:From pump
T
:T
o tank
A, B
: High pressure port,
Return port
178
180
