2.Engine model and engine serial number plate on the head cover.
1) Engine model identification location
(a) The model identification is embosses on the
right side of the cylinder block,near the fuel
Injection pump mount.
(b) The model identifications and displacements
of the engines in current production are as listed
below
(c) A scheme of coding used for identifying the
engines in the current production is as follows:
Example : Coded designation
Displacement
S3L 1.125 liters(68.7 cu in.)
S3L2 1.318 liters(80.4 cu in.)
S4L 1.500 liters(91.5 cu in.)
S4l2 1.758 liters(107.3 cu in.)
1-15
Example : Coded designation
2) Serial number location
The serial number is punched on the cylinder block,
Near the fuel injection pump mount
S 3 L (2) – 61 A
Specification code
Export code
Stroke code(No code:78.5 mm(3.09 in),2:92 mm(3.62 in)
Serial code[Bore:78 mm(3.07 in)]
Number-of –cylinder[“3”stands for three cylinders]
Identification of ”Sagamihara Machinery Works”
