MODEL T233 HST T273 HST
PTO Type Independent
Control Electro-Hydraulic
Clutch Multiple wet Disk
Rear PTO Shaft SAE 1-3/8,6 spline
Speed 540rpm@Engine 2,775rpm
Mid PTO Shaft 10 Splines
Speed 2,000rpm@Engine 2,650rpm
Hydraulics Control system Open Center Open Center
Working pressure 1,813psi( 125bar) 1,813psi( 125bar)
Pump capacity Main 5.0 GPM(18.9 LPM)
Steering 2.6 GPM(10LPM)
3―Point
Hitch
Type
SAE Category Ⅰ
Control Position Position
Lift Control At lift points 1,653lb(750kg)
At 24 in behind
Lift point
1,213lb(550 kg)
Overall Width 49.6 in(1,260mm)
Overall height 78.74 in(2,000mm)
Wheel base 58.26 in(1,480mm)
Min.Ground clearance 11.81 in(300mmm) 11.81 in(300mm)
Tread R1 Front 6-12,4PR 6-14,4PR
Rear 9.5-16,4PR 11.2-20
R3 Front 23X8.50-12,4PR 23X8.50-12,4PR
Rear 12X16.5 ,4PR 12X16.5 ,4PR
R4
(Std.)
Front 23X8.50-12,4PR 23X8.50-12,4PR
Rear 12X16.5,6PR 12X16.5,6PR
Weight
