TYM T233 HST User Manual

(3) Turn signal switch
●Turn signal
switch
Replace a defective
switch assembly.
(4) Horn switch
●Horn switch
Replace a defective
switch assembly.
(5) PTO SWITCH
Continuity across
each terminal
Switched on when lever is moved by about 3 mm
(0.12 in) across R and LR
Replace a defective
switch assembly.
(6) STOP LIGHT SWITCH
11-7
(6) STOP LIGHT SWITCH
Continuity across
each terminal
Switched on when actuator is pushed in by
about 3 mm(0.12 in)assembly
Replace a defective
switch assembly.
(7) HAZARD WARNING SWITCH
Continuity across
each terminal
Replace a defective
switch assembly.
○ ○ ○ ○
○ ○ ○ ○ ○ ○
○ ○
ON
11
10 9 7 6 4 3 1
2
5
811
OFF
