27
Temperature Controller
Figure 23
The temperature controls are integrated in the top, front drawer panel.
They consist of an LED display and touch sensors for each drawer and
a touch sensor to control the lighting (“ ”, “ ” and “ ”). The LED dis-
plays show the drawer’s temperature set point, and are calibrated in
degrees Fahrenheit. The controls are factory programmed for a set
point of 60°F for the top drawer and 40° F for the bottom drawer. Each
drawer’s display will show its set point when the unit is first powered up.
Figure 24
To display actual temperature of each drawer, press the “ ” and “ ”
touch sensors simultaneously for three seconds. The display indicates
the actual temperature. After approximately 10 seconds, the set point
temperature displays.
