4. – Connect the water supply line. See CONNECTING THE
WATER SUPPLY for installation requirements.
5. Position the unit to allow free air flow through the front grille
(Figure 4).
Figure 4
6. Wipe inside of unit and all inside drawer components with a clean,
water dampened cloth only.
LEVELING THE UNIT
It is important that the unit is level. All Échelon™ Series units are
equipped with adjustable feet for leveling and height adjustment
(Figure 5).
To level the unit:
1. Adjust all four leveling feet evenly so that the top of the cabinet is at
the desired installation height.
2. Using a level of at least two feet in length, measure the level of the
floor where the unit is to be installed. Measure back-to-front and
side-to-side and note the measurements.
3. With the unit on a level surface, adjust the feet, as appropriate, to
compensate for the floor level measurements noted in Step 2.
