User’s Manual
To remove and replace the grille for access to the condenser fins
follow this procedure:
Figure 36
1. Remove the screws (Figure 36) at each end of the grille.
2. Remove the grille.
DO NOT touch the condenser fins. The condenser fins are
SHARP and can be easily damaged.
3. Clean the condenser coil using a soft brush with a “combing” action
or vacuum cleaner. Do not touch the condenser coil.
4. Position the grille to align the screw holes with the cabinet.
5. Insert the grille screws and tighten. Do not overtighten.
